Trash Garbage and Linen Chutes and Chute Systems

Garbage Chute

A garbage chute system is a long vertical space passing by each floor in a building. It includes a door on each floor where residents can dispose of their garbage into the chute. This door is usually contained in a small room on each floor. Garbage placed in the chute drops to a compactor or dumpster at the bottom.

Linen chute

A passage in the form of a tunnel for sending soiled linen from the floor pantries of all floors to a central place near the laundry, from where it can be collected by the laundry staff.

S.S. Garbage or Linen Chute Size Dia 24″

chute tube made of 1.50mm SS 304

with Sound deadening material

DOORS

Number Of Doors 13 Chute Door material 1.50mm SS 304 AT EACH FLOOR STAINLESS STEEL DOOR SIZE 57 x 73 cm NETOPENING 45 X 45 cm 30 LITRE CAPACITY, BOTTOM HINGED. PROVIDED WITH ELECTRO MAGNETIC LOCK AND INDICATOR. Handle made of 8.00mm SS Rod 304 Insulation in Doors 2″x 48kg Glass wool FAN Ventilation Fan Axial Type 1500 cfm on Terminal

MOUNTING

M.S. Frame 1.5″x 1.5″x5.00mm M.S. Angle M.S. Ring 3″x5.00mm M.S. Flat

Electric work

PLC PANEL ; DELTA PLC WITH 24″x36″ MS POWDER COUTED PANEL ,13 FLOORS DOOR STATUS INDICATION, LOCK/ UNLOCK WITH INTERLOCKING SAFTY & INDIVIDUAL FLOOR OPRERATING SYSTEM & WATER JET CLEAN SYSTEM ACCORDINGLY TO DRAWING WITH COMPLETE ELECTRIFICATION , INSTALLATION,COMMIONING & CABLE LAYING.

WATER JET/BOOSTER PUMP

JET/BOOSTER PUMP SYSTEM WITH 14NOS NOZZLE ALONG WITH 250′ RFT PIPING ,SLONIODE VALVE ACCORDINGLY TO DRAWING FIRE WATER SPRINKLE POINT EXTENSION JFIRE WATER SPRINKLE 13NOS POINT WITH PIPING ACCORDINGLY TO DRAWING M.S. Pipe Fitting will be painted
